Red 10mm LED 9600mcd Round Clear
Red 10mm LED 9600mcd Round Clear
Specifications:
| Diameter | 10mm |
| LED Type | 10mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 625nm |
| Lens Type | waterclear |
| Viewing Angle | 30° |
| Intensity | 4500mcd |
| Vf (typ) - Typical Forward Voltage | 2V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 150Ω |
| Resistor for 9VDC | 360Ω |
| Resistor for 12VDC | 510Ω |
Downloads
- Download Datasheet
Red 10mm LED 9600mcd Round Clear
Specifications:
| Diameter | 10mm |
| LED Type | 10mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 625nm |
| Lens Type | waterclear |
| Viewing Angle | 30° |
| Intensity | 4500mcd |
| Vf (typ) - Typical Forward Voltage | 2V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 150Ω |
| Resistor for 9VDC | 360Ω |
| Resistor for 12VDC | 510Ω |
Downloads
- Download Datasheet
$1.27
Red 10mm LED 9600mcd Round Clear—
$1.27
Description
Red 10mm LED 9600mcd Round Clear
Specifications:
| Diameter | 10mm |
| LED Type | 10mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 625nm |
| Lens Type | waterclear |
| Viewing Angle | 30° |
| Intensity | 4500mcd |
| Vf (typ) - Typical Forward Voltage | 2V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 150Ω |
| Resistor for 9VDC | 360Ω |
| Resistor for 12VDC | 510Ω |
Downloads
- Download Datasheet
