LED 5mm Red Waterclear 35000mcd
LED 5mm Red Waterclear 35000mcd
Specifications:
| Diameter | 5mm |
| LED Type | 5mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 616nm |
| Lens Type | waterclear |
| Viewing Angle | 8° |
| Intensity | 35000mcd |
| Vf (typ) - Typical Forward Voltage | 2.1V |
| If (typ) - Typical Forward Current | 50mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 62Ω |
| Resistor for 9VDC | 150Ω |
| Resistor for 12VDC | 200Ω |
Downloads
- Download Datasheet
LED 5mm Red Waterclear 35000mcd
Specifications:
| Diameter | 5mm |
| LED Type | 5mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 616nm |
| Lens Type | waterclear |
| Viewing Angle | 8° |
| Intensity | 35000mcd |
| Vf (typ) - Typical Forward Voltage | 2.1V |
| If (typ) - Typical Forward Current | 50mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 62Ω |
| Resistor for 9VDC | 150Ω |
| Resistor for 12VDC | 200Ω |
Downloads
- Download Datasheet
$0.55
Original: $1.56
-65%LED 5mm Red Waterclear 35000mcd—
$1.56
$0.55Description
LED 5mm Red Waterclear 35000mcd
Specifications:
| Diameter | 5mm |
| LED Type | 5mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Red |
| Light Wavelength | 616nm |
| Lens Type | waterclear |
| Viewing Angle | 8° |
| Intensity | 35000mcd |
| Vf (typ) - Typical Forward Voltage | 2.1V |
| If (typ) - Typical Forward Current | 50mA |
| If (max) - Maximum Forward Current | 50mA |
| Resistor for 5VDC | 62Ω |
| Resistor for 9VDC | 150Ω |
| Resistor for 12VDC | 200Ω |
Downloads
- Download Datasheet
