Green 3mm LED 40mcd Round Diffused
Green 3mm LED 40mCd Round Diffused
Specifications:
| Diameter | 3mm |
| LED Type | 3mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Green |
| Light Wavelength | 573nm |
| Lens Type | Diffused |
| Viewing Angle | 50° |
| Intensity | 40mcd |
| Vf (typ) - Typical Forward Voltage | 2.3V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 20mA |
| Resistor for 5VDC | 130Ω |
| Resistor for 9VDC | 330Ω |
| Resistor for 12VDC | 470Ω |
Downloads
- Download Datasheet
Green 3mm LED 40mCd Round Diffused
Specifications:
| Diameter | 3mm |
| LED Type | 3mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Green |
| Light Wavelength | 573nm |
| Lens Type | Diffused |
| Viewing Angle | 50° |
| Intensity | 40mcd |
| Vf (typ) - Typical Forward Voltage | 2.3V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 20mA |
| Resistor for 5VDC | 130Ω |
| Resistor for 9VDC | 330Ω |
| Resistor for 12VDC | 470Ω |
Downloads
- Download Datasheet
$0.08
Original: $0.23
-65%Green 3mm LED 40mcd Round Diffused—
$0.23
$0.08Description
Green 3mm LED 40mCd Round Diffused
Specifications:
| Diameter | 3mm |
| LED Type | 3mm Standard LED |
| Illumination Type | Single Colour |
| Light Colour | Green |
| Light Wavelength | 573nm |
| Lens Type | Diffused |
| Viewing Angle | 50° |
| Intensity | 40mcd |
| Vf (typ) - Typical Forward Voltage | 2.3V |
| If (typ) - Typical Forward Current | 20mA |
| If (max) - Maximum Forward Current | 20mA |
| Resistor for 5VDC | 130Ω |
| Resistor for 9VDC | 330Ω |
| Resistor for 12VDC | 470Ω |
Downloads
- Download Datasheet
