70RPM 12VDC Reversible Gearhead Motor
Compact reversible DC motor with gearbox head for small scale applications. Suitable for small robotics and drive applications.
Operating Voltage 12VDC
At Stall:
Torque: 2.1kg.cm
Current: 350mA
Specifications:
| Motor Type | Gearhead |
| Motor Nominal Voltage | 12V |
| No load current | 30mA |
| Full load current | 390mA |
| Full load torque | 2.1kg.cm |
| No load RPM | 70RPM |
| Max efficiency RPM | 59RPM |
| Max efficiency | 49.3% |
| Max. efficiency current | 110mA |
| Max efficiency power | 1.3W |
| Maximum efficiency torque | 480g.cm |
| Shaft diameter | 4mm |
| Shaft length | 8.8mm |
| Item connection | Solder Tags |
| DC Voltage | 4.5V-18V |
| Adjustable Gear | No |
| Type | Planetary/Orbital |
| Gear Ratio | 82:1 |
| Pre-assembled Gear | Yes |
Downloads
- Download Datasheet
Compact reversible DC motor with gearbox head for small scale applications. Suitable for small robotics and drive applications.
Operating Voltage 12VDC
At Stall:
Torque: 2.1kg.cm
Current: 350mA
Specifications:
| Motor Type | Gearhead |
| Motor Nominal Voltage | 12V |
| No load current | 30mA |
| Full load current | 390mA |
| Full load torque | 2.1kg.cm |
| No load RPM | 70RPM |
| Max efficiency RPM | 59RPM |
| Max efficiency | 49.3% |
| Max. efficiency current | 110mA |
| Max efficiency power | 1.3W |
| Maximum efficiency torque | 480g.cm |
| Shaft diameter | 4mm |
| Shaft length | 8.8mm |
| Item connection | Solder Tags |
| DC Voltage | 4.5V-18V |
| Adjustable Gear | No |
| Type | Planetary/Orbital |
| Gear Ratio | 82:1 |
| Pre-assembled Gear | Yes |
Downloads
- Download Datasheet
