6V DIL SPDT Mini Relay
Low profilem, 6V DC bobbin relay
Specifications:
| Coil Resistance | 100Ω |
| Device Type | Standard Coil Relay |
| Input | AC |
| Contact format | SPDT |
| AC Contact Voltage | 125V |
| AC Switching Current (Opening) | 1A |
| DC Voltage | 6V |
| AC Voltage | 125V |
| DC Current Draw | 1A |
| AC Current Draw | 1A |
| Mounting Method | PCB |
| Width | 15mm |
| Height | 11mm |
| Depth | 11mm |
Downloads
- Download Datasheet
Low profilem, 6V DC bobbin relay
Specifications:
| Coil Resistance | 100Ω |
| Device Type | Standard Coil Relay |
| Input | AC |
| Contact format | SPDT |
| AC Contact Voltage | 125V |
| AC Switching Current (Opening) | 1A |
| DC Voltage | 6V |
| AC Voltage | 125V |
| DC Current Draw | 1A |
| AC Current Draw | 1A |
| Mounting Method | PCB |
| Width | 15mm |
| Height | 11mm |
| Depth | 11mm |
Downloads
- Download Datasheet
