30mm Thin 12VDC 2 Wire Fan
Suitable for computers, office machinery, appliances, copying machines, power units, amplifiers, automatic vending machines, air conditioning, medical machines etc.
- Long life - 60,000 hours @ 25degC, 30,000 hours @ 40degC
- Ball bearing: 100,000 hours @ 25degC
- Can be mounted on suction or discharge side
- Wiring will not burn out, even if rotating parts are restricted.
Specifications:
| fan RPM | 8000RPM |
| fan air colume cubic feet | 3.09ft³/min |
| fan noise | 21dB |
| type of fan | Axial |
| fan air volume cubic metres | 0.108m³/min |
| fan bearing type | Ball |
| fan housing material | Plastic |
| fan impeller material | Plastic |
| Fan Operational Life at 25°C | 40000hr |
| fan number of wires | 2pc |
| fan connector type | Flyleads |
| Item Connection | Flyleads |
| DC Plugpack Voltage | 12V |
| DC Current Draw | 100mA |
| Length | 30mm |
| Width | 6mm |
| Height | 30mm |
Downloads
- Download Datasheet
Suitable for computers, office machinery, appliances, copying machines, power units, amplifiers, automatic vending machines, air conditioning, medical machines etc.
- Long life - 60,000 hours @ 25degC, 30,000 hours @ 40degC
- Ball bearing: 100,000 hours @ 25degC
- Can be mounted on suction or discharge side
- Wiring will not burn out, even if rotating parts are restricted.
Specifications:
| fan RPM | 8000RPM |
| fan air colume cubic feet | 3.09ft³/min |
| fan noise | 21dB |
| type of fan | Axial |
| fan air volume cubic metres | 0.108m³/min |
| fan bearing type | Ball |
| fan housing material | Plastic |
| fan impeller material | Plastic |
| Fan Operational Life at 25°C | 40000hr |
| fan number of wires | 2pc |
| fan connector type | Flyleads |
| Item Connection | Flyleads |
| DC Plugpack Voltage | 12V |
| DC Current Draw | 100mA |
| Length | 30mm |
| Width | 6mm |
| Height | 30mm |
Downloads
- Download Datasheet
$16.66
30mm Thin 12VDC 2 Wire Fan—
$16.66
