Sealed lead Acid Battery 12V 2.2Ah
Features:
Charge current: 220 mA for 10-14 hours
Discharge current: 20 hour rate 110mA
• Max Discharge Current: (5 sec.) 40Ah
• Initial charging current: >0.66A @ 14.4
• 15V @ 20°C.- Temp. coefficient: -30mV/°C
• Standby: 13.5 - 13.8V @ 20°C.
• Temp. coefficient: -20mV/°C
For More info on Charging Batteries.
| Recharging Voltage | 14.4V-15V |
| Standard Recharge Current | 220mA |
| Recharging Time | 20hr |
| DC Voltage | 12V |
| Length | 178mm |
| Height | 66mm |
| Depth | 34mm |
| Battery Chemical Composition | Sealed Lead Acid (SLA) |
| Battery usage | Rechargeable |
| Battery Peak Current | 33A |
| Amp Hour Rating | 2.2Ah |
| 20 Hour Capacity | 2.2Ah |
| 10 Hour Capacity | 1.98Ah |
| 5 Hour Capacity | 3.52Ah |
| 1 Hour Capacity | 1.32Ah |
| Connection Type | Spade Terminals |
| Type of battery | SLA Block |
| Internal Resistance | 50Ω |
Downloads
Features:
Charge current: 220 mA for 10-14 hours
Discharge current: 20 hour rate 110mA
• Max Discharge Current: (5 sec.) 40Ah
• Initial charging current: >0.66A @ 14.4
• 15V @ 20°C.- Temp. coefficient: -30mV/°C
• Standby: 13.5 - 13.8V @ 20°C.
• Temp. coefficient: -20mV/°C
For More info on Charging Batteries.
| Recharging Voltage | 14.4V-15V |
| Standard Recharge Current | 220mA |
| Recharging Time | 20hr |
| DC Voltage | 12V |
| Length | 178mm |
| Height | 66mm |
| Depth | 34mm |
| Battery Chemical Composition | Sealed Lead Acid (SLA) |
| Battery usage | Rechargeable |
| Battery Peak Current | 33A |
| Amp Hour Rating | 2.2Ah |
| 20 Hour Capacity | 2.2Ah |
| 10 Hour Capacity | 1.98Ah |
| 5 Hour Capacity | 3.52Ah |
| 1 Hour Capacity | 1.32Ah |
| Connection Type | Spade Terminals |
| Type of battery | SLA Block |
| Internal Resistance | 50Ω |
Downloads
Original: $17.24
-65%$17.24
$6.03Description
Features:
Charge current: 220 mA for 10-14 hours
Discharge current: 20 hour rate 110mA
• Max Discharge Current: (5 sec.) 40Ah
• Initial charging current: >0.66A @ 14.4
• 15V @ 20°C.- Temp. coefficient: -30mV/°C
• Standby: 13.5 - 13.8V @ 20°C.
• Temp. coefficient: -20mV/°C
For More info on Charging Batteries.
| Recharging Voltage | 14.4V-15V |
| Standard Recharge Current | 220mA |
| Recharging Time | 20hr |
| DC Voltage | 12V |
| Length | 178mm |
| Height | 66mm |
| Depth | 34mm |
| Battery Chemical Composition | Sealed Lead Acid (SLA) |
| Battery usage | Rechargeable |
| Battery Peak Current | 33A |
| Amp Hour Rating | 2.2Ah |
| 20 Hour Capacity | 2.2Ah |
| 10 Hour Capacity | 1.98Ah |
| 5 Hour Capacity | 3.52Ah |
| 1 Hour Capacity | 1.32Ah |
| Connection Type | Spade Terminals |
| Type of battery | SLA Block |
| Internal Resistance | 50Ω |
